YC200-3V2D2U Modular PLC CPU (3 Voltage AI/2AO/2Serial)

YC200-3V2D2U Modular PLC CPU (3 Voltage AI/2AO/2Serial)-thumb-3

YC200-3V2D2U Modular PLC CPU (3 Voltage AI/2AO/2Serial)-thumb-4

YC200-3V2D2U Modular PLC CPU (3 Voltage AI/2AO/2Serial)-thumb-5

Click to preview

YC200-3V2D2U Modular PLC CPU (3 Voltage AI/2AO/2Serial)

High-precision bipolar analog controller CPU featuring 3x ±10V bipolar voltage inputs, 2x ±10V analog outputs, 2 serial ports, and multi-bus interfaces for rapid voltage acquisition and closed-loop control.

Technical Specifications

Power Supply	24V DC Nominal Industrial Supply
I/O Channels	3× Bipolar Voltage AI (±10V) + 2AO (±10V) + 2 Serial + 3×RJ45
Serial & Ports	COM1 (TTL/RS232) + COM2 (RS232/TTL) + RS485A/B
Network & Ethernet	ETH1 (Debug) + ETH2 (CAN/485) + ETH3 (Industrial Ethernet)
Backplane Bus	CAN 2.0A/B High-Speed Backplane
Selection Guide	Designed for bipolar voltage sensing, differential displacement sensors, load-cell strain inputs, and servo command closed-loop systems.

Application Scenarios

Engineered to empower diverse industrial, metrology, and intelligent IoT scenarios.

Bioprocess & Fermentation

FLR1000 Fermenter End-to-End Control

Delivers multi-channel thermal PID loop, pH regulation, automated dosing valves, and 10.1-inch bilingual HMI synergy for advanced bioreactors.

Smart Manufacturing

Assembly Lines, Packaging & Tooling Control

Combines YC200 CPU with YM200 16I/16O modules for microsecond sensor reading and solenoid actuation, supporting mixed LD and ST programming.

Distributed Utilities

Unattended Pumping Stations & Water Utilities

Native industrial Ethernet and RS-485 links smart flowmeters and circuit breakers directly to Web SCADA over MQTT with offline resilience.

High Reliability & Zero Power

Latching Relay Bistable & State Retention

Employs YM200-04M latching modules to retain valve and contact states during power failures with zero steady-state power consumption.

Product Advantages

High Precision & StabilityEngineered to stringent metrological and industrial standards with exceptional repeatability and long-term durability.

IoT & Cloud EcosystemNative integration with YiOS IoT platform and WebConsole tools for remote telemetry and automated reporting.

Modular & Easy IntegrationStandardized interfaces and plug-and-play architecture significantly reduce on-site deployment and integration costs.

Model Selection Reference

Model	Product Name	Category	Description
YC200-3V2D2U	YC200-3V2D2U Modular PLC CPU (3 Voltage AI/2AO/2Serial)	plc	High-precision bipolar analog controller CPU featuring 3x ±10V bipolar voltage inputs, 2x ±10V analog outputs, 2 serial ports, and multi-bus interfaces for rapid voltage acquisition and closed-loop control.
